日本麦格特Mighty联轴器MJC-33-10-14/MJC-25-6-9
发布时间：2024-09-27
日本麦格特Mighty联轴器MJC-33-10-14/MJC-25-6-9
Flexible Shaft Coupling (MJC-33-11X14)
Oldham, Clamping, MJC Series
Part Number: MJC-33-11X14
•Application : Encoder, Servo Motor, Standard, Stepping Motor
•Body Material : Aluminum Alloy
•Allowable Misalignment : Angular, Eccentricity
•Feature : High Accuracy, High Durability, No Backlash, Vibration Insulation
For complete product overview and details on Oldham Coupling, MJC Series see the sections below:
Configured Specifications
| Type | Oldham | Allowable Misalignment | Angular Misalignment / Eccentricity |
|---|---|---|---|
| Application | Standard / Servo Motor / Stepping Motor / Encoder | Allowable Torque Range(N⋅m) | 5.01 to 10.00 |
| For Shaft Size D1(mm) | 11 | For Shaft Size D2(mm) | 14 |
| Outer Diameter A(Ø) | 33.3 | Overall Length W(mm) | 48 |
| Features | High accuracy / High durability / Backlash 0 / Vibration Absorption | Body Material | [Aluminum] Aluminum Alloy |
| Allowable Torque(N⋅m) | 10 | Allowable Angular Misalignment(deg) | 1 |
| Allowable Lateral Misalignment Range(mm) | 3.1 to 5.0 | Allowable Lateral Misalignment(mm) | 3.8 |
| Buffer Part Material | Polyacetal | Moment of Inertia(kg·m2) | 1210X10-8 |
| Mounting Method | Clamping | Specification | Clamp locking |
| RoHS | 10 | - | - |
