日本KYOWA共和网络数据采集器NTB-100B-120

Description

NTB-100/200 Series, Network Terminal Box

The NTB-100/200 Series is a data logger, which digitizes data from the sensor and can be decentralized arrangement.

A single unit measures 4 channels, and allows up to 99 units to be connected, so measurement up to 396 channels is possible.

NTB-100B-120, Constant-voltage, one-touch terminal, 120 Ω,

Channels: 4

Measuring Target: Strain gages, strain-gage transducers

• Quarter bridge 120 Ω

• Half-bridge 120 to 1000 Ω Active-active system

• Full bridge 120 to 1000 Ω Full bridge

NTB-100B-350, Constant-voltage, one-touch terminal, 350 Ω

Channels: 4

Measuring Target: Strain gages, strain-gage transducers

• Quarter bridge 350 Ω

• Half-bridge 120 to 1000 Ω Active-active system

• Full bridge 120 to 1000 Ω Full bridge

NTB-101A-120, Constant-voltage screw soldering terminal, 120 Ω

Channels: 4

Measuring Target: Strain gages, strain-gage transducers

• Quarter bridge 120 Ω

• Half-bridge 120 to 1000 Ω Active-active system

• Full bridge 120 to 1000 Ω Full bridge

NTB-101A-350, Constant-voltage screw soldering terminal, 350 Ω

Cannels: 4

Measuring Target: Strain gages, strain-gage transducers

• Quarter bridge 350 Ω

• Half-bridge 120 to 1000 Ω Active-active system

• Full bridge 120 to 1000 Ω Full bridge

NTB-110B-350, Constant-current, one-touch terminal

Channels: 4

Measuring Target: Civil engineering transducers

• Full bridge 350 Ω Full bridge

• Full bridge 350 Ω Civil engineering transducer with thermal sensors

NTB-111A-350, Constant-current, screw soldering terminal

Channels: 4

Measuring Target: Civil engineering transducers

• Full bridge 350 Ω Full bridge

• Full bridge 350 Ω Civil engineering transducer with thermal sensors

NTB-201A, DC Voltage-output, thermocouples

Channels: 4

Measuring Target: DC voltage-output, thermocouples

Voltage-Output Measurement: [Range 10 V]

• Measuring range: 0 to ±10.0000 V

• Resolution: 100 μV

Thermocouples:

• Type K: Measuring range: -200.0 to 1230.0°C

• Type T: Measuring range: -200.0 to 400.0°C

• Type E: Measuring range: -200.0 to 660.0°C

• Type J: Measuring range: -200.0 to 870.0°C

• Type R: Measuring range: 0.0 to 1760.0°C

• Type N: Measuring range: -200.0 to 1300.0°C

NTB-20A, NTB power supply box

Power Save Function (AUTO Mode): When the PC power supply is OFF, then the power supply of the NTB-20 connected by a USB cable is off.

NTB-21A, NTB relay box

Power Supply Output Limitation Function: When power supply exceeding the range is input into NTB, the power supply output from the serial connector is turned to OFF.

NTB-10A, Network terminal box control software
