日本OZAK轴承LFK16BUU

表27：LFK, MLFK, ULFK, UMLFKシリーズ寸法表スタンダード ウルトラシリーズ 主　　要　　寸　　法　　（㎜）玉列数質量 基本定格荷重標　準　型シールなし両シール付防　錆　型シールなし両シール付標　準　型両シール付防　錆　型両シール付フ ラ　ン　ジ C Cod D L Df K t Dp S （kg）（N）（N）LFK6LFK6-UUMLFK6MLFK6-UU ULFK6-UU UMLFK6-UU 60－0.009120－0.021 19 28 22 5 20 M3 4 0.023 218 160LFK8LFK8-UUMLFK8MLFK8-UU ULFK8-UU UMLFK8-UU 8 16 25 32 25 5 24 M3 4 0.039 258 220LFK8BLFK8B-UUMLFK8BMLFK8B-UU ULFK8B-UU UMLFK8B-UU 8 15 24 32 25 5 24 M3 4 0.029 258 220LFK10LFK10-UUMLFK10MLFK10-UU ULFK10-UU UMLFK10-UU 10 19 29 39 30 6 29 M4 4 0.061 532 430LFK12LFK12-UUMLFK12MLFK12-UU ULFK12-UU UMLFK12-UU 12 22 32 42 32 6 32 M4 4 0.081 549 430LFK12BLFK12B-UUMLFK12BMLFK12B-UU ULFK12B-UU UMLFK12B-UU 12 21 30 42 32 6 32 M4 4 0.070 549 430LFK13LFK13-UUMLFK13MLFK13-UU ULFK13-UU UMLFK13-UU 13 23 32 43 34 6 33 M4 4 0.080 555 440LFK16LFK16-UUMLFK16MLFK16-UU ULFK16-UU UMLFK16-UU 16 26 36 46 35 6 36 M4 5 0.100 768 650LFK16BLFK16B-UUMLFK16BMLFK16B-UU ULFK16B-UU UMLFK16B-UU 16 28 37 48 37 6 38 M4 5 0.109 768 650LFK20LFK20-UUMLFK20MLFK20-UU ULFK20-UU UMLFK20-UU 200－0.010320－0.025 42 54 42 8 43 M5 5 0.176 1282 1010LFK25LFK25-UUMLFK25MLFK25-UU ULFK25-UU UMLFK25-UU 25 40 58 62 50 8 51 M5 6 0.300 2164 1790LFK30LFK30-UUMLFK30MLFK30-UU ULFK30-UU UMLFK30-UU 30 47 64 76 60 10 62 M6 6 0.55 3245 2510LFK30BLFK30B-UUMLFK30BMLFK30B-UU ULFK30B-UU UMLFK30B-UU 30 45 64 74 58 10 60 M6 6 0.43 3245 2510LFK35LFK35-UUMLFK35MLFK35-UU ULFK35-UU UMLFK35-UU 350－0.012520－0.030 70 82 64 10 67 M6 6 0.59 3521 3090LFK40LFK40-UUMLFK40MLFK40-UU ULFK40-UU UMLFK40-UU 40 60 80 96 75 13 78 M8 6 1.21 4844 4040LFK50LFK50-UUMLFK50MLFK50-UU ULFK50-UU UMLFK50-UU 50 80 100 116 92 13 98 M8 6 1.99 8272 6430LFK60LFK60-UUMLFK60MLFK60-UU ULFK60-UU UMLFK60-UU 60 0－0.015 90 0－0.035 110 134 106 18 112 M10 6 3.20 9847 7270角
