日本IKEUCHI池内喷嘴1/4M INVV 9010 PP(FEPM)+PPS
日本IKEUCHI池内喷嘴1/4M INVV 9010 PP(FEPM)+PPS
Configured Specifications
| Spray Pattern | Straight | Air Source | Compressor |
|---|---|---|---|
| Material | [Plastic] PPS (Polyphenylene sulfide) | Mounting Angle | Flat |
| Blow Type | Amplification type | Type | Air Nozzle |
| Applicable Fluid | Air, compressed air | Operating Pressure Range(MPa) | ～0.7 |
| Nominal Mounting Screw | R1/4 | Injection Width(mm) | 42 |
| Heat Resistant Temperature(℃) | 130 | RoHS | 10 |
Product Description
A unique flat design for a more even injection of air. Made from PPS with excellent heat and chemical resistance.
A low-noise product for use in work environments.
[Features]
· TAIFUJet series products have a novel structure that traps the surrounding air and then powerfully blows the amplified air. · A unique design with an even and strong injection force, and with excellent low-noise and straight injection performance.
· Energy saving (volume of amplified air) and with a powerful impact performance: TAIFUJet features a unique design that traps and amplifies the surrounding air. Powerful air injection, even with low air consumption.
· Low-noise design: TAIFUJet, in addition to featuring a work environment-friendly and low-noise design, is available in flat and round types to fit the application.
· Evenness: TAIFUJet features a unique design that injects air more evenly. By phasing the top and bottom injection ports and air suction holes, an even spray across the entire spray width can be obtained. Attenuation of the impact force as distance increases is small, allowing for the air blower to operate more efficiently.
