Manufacturer :Yokogawa
Product No. : AAI543-H50/K4A00
Product Type : Analog Output Module
H : With digital communication (HART protocol)
5 : Standard switch-over response in redundant configuration with no explosion protection
0 : Basic type
K4A00 : With KS Cable Interface Adapter (For connecting AEA4D Terminal Board) [Model: ATK4A-00]
Number of output channels : 16, isolated, standard switch-over response in redundant configuration
Input signal : 4 to 20 mA
Withstanding voltage : Between output and system: 1500 V AC, for 1 minute
Allowable load resistance 0 to 750
Circuit-open detection Less than 0.65 mA
Accuracy : ±48 µA
Data update period : 10 ms
Drift due to ambient temperature change : ±16 µA/10 °C
Maximum current consumption : 230 mA (5 V DC), 540 mA (24 V DC)
External communication : Pressure clamp terminal, MIL connector cable, dedicated cable (KS1)
Weight : 0.4 Kg
Shipping Weight : 1.5 Kg
