日本NOP摆线齿轮泵TOP-206HBM

Model / Item	Theoretical Displacement (cm³/rev)	Theoretical Discharge (L/min)		Max. Pressure (MPa)	Max. Revolution (min^-1)	Approx. Weight (kg)
Model / Item	Theoretical Displacement (cm³/rev)	1500min^-1	1800min^-1	Max. Pressure (MPa)	Max. Revolution (min^-1)	Approx. Weight (kg)
TOP-203HB	2.8	4.2	5.0	3.0	3,000	3.5
TOP-204HB	4	6.0	7.2	3.0	3,000	3.6
TOP-206HB	6	9.0	10.8	2.5	2,500	3.8
TOP-208HB	8	12.0	14.4	2.5	2,500	4.0
TOP-210HB	10	15.0	18.0	2.5	2,500	4.1
TOP-212HB	12	18.0	21.6	2.0	2,000	4.3
TOP-216HB	16	24.0	28.8	1.5	1,800	4.6
TOP-220HB	20	30.0	36.0	1.2	1,800	5.0

Performance Table

・Standard discharge rate and required power at 1450 min^-1 (50Hz)

Model / Specifications	Discharge Rate (L/min)							Required Power (W)
	Pressure (MPa)							Pressure (MPa)
	0.1	0.5	1.0	1.5	2.0	2.5	3.0	0.1	0.5	1.0	1.5	2.0	2.5	3.0
TOP-203HB	4.0	4.0	3.9	3.9	3.8	3.8	3.7	48	84	131	178	228	277	325
TOP-204HB	5.8	5.7	5.6	5.6	5.5	5.4	5.3	66	110	169	227	283	340	394
TOP-206HB	8.7	8.6	8.5	8.4	8.3	8.2	-	86	158	240	329	415	497	-
TOP-208HB	11.6	11.5	11.5	11.4	11.4	11.3	-	91	186	305	423	543	662	-
TOP-210HB	14.4	14.4	14.3	14.0	13.9	13.8	-	104	210	345	480	615	749	-
TOP-212HB	17.4	17.2	17.0	16.8	16.6	-	-	123	250	405	565	730	-	-
TOP-216HB	23.1	22.9	22.8	22.4	-	-	-	148	308	510	715	-	-	-
TOP-220HB	28.9	28.7	28.4	-	-	-	-	205	396	633	-	-	-	-

Above data was taken by the oil:ISO-VG 46 at 40 Celsius

Performance Table

・Standard discharge rate and required power at 1750 min^-1 (60Hz)

Model / Specifications	Discharge Rate (L/min)							Required Power (W)
	Pressure (MPa)							Pressure (MPa)
	0.1	0.5	1.0	1.5	2.0	2.5	3.0	0.1	0.5	1.0	1.5	2.0	2.5	3.0
TOP-203HB	4.9	4.8	4.8	4.7	4.7	4.6	4.5	58	101	158	215	272	330	386
TOP-204HB	7.0	6.9	6.8	6.7	6.7	6.6	6.5	80	133	204	274	342	410	476
TOP-206HB	10.4	10.3	10.2	10.1	10.0	9.9	-	104	188	290	397	500	599	-
TOP-208HB	14.0	13.9	13.8	13.8	13.8	13.7	-	110	225	368	510	655	800	-
TOP-210HB	17.6	17.5	17.2	17.0	16.9	16.7	-	125	250	413	575	740	904	-
TOP-212HB	21.0	20.9	20.6	20.4	20.2	-	-	148	302	488	681	881	-	-
TOP-216HB	27.8	27.7	27.4	27.0	-	-	-	179	372	616	863	-	-	-
TOP-220HB	34.8	34.6	34.3	-	-	-	-	248	478	764	-	-	-	-

Above data was taken by the oil:ISO-VG 46 at 40 Celsius

2MY-2HBM

Required Power of Trochoid Pump

Model / Item	1500min^-1 (50Hz)					1800min^-1 (60Hz)
	Theoretical Discharge (L/min)	Max. Pressure for Motor Output (MPa)				Theoretical Discharge L/min	Max. Pressure for Motor Output (MPa)
	Theoretical Discharge (L/min)	200W	400W	750W	1500W	Theoretical Discharge L/min	200W	400W	750W	1500W
TOP-203HBM	4.2	1.7	3.0	3.0	3.0	5.0	1.3	3.0	3.0	3.0
TOP-204HBM	6.0	1.2	3.0	3.0	3.0	7.2	0.9	2.3	3.0	3.0
TOP-206HBM	9.0	0.7	1.8	2.5	2.5	10.8	0.5	1.4	2.5	2.5
TOP-208HBM	12.0	0.5	1.3	2.5	2.5	14.4	0.3	1.0	2.3	2.5
TOP-210HBM	15.0	0.4	1.1	2.5	2.5	18.0	0.3	0.9	2.0	2.5
TOP-212HBM	18.0	0.3	0.9	2.0	2.0	21.6	-	0.7	1.6	2.0
TOP-216HBM	24.0	0.2	0.7	1.5	1.5	28.8	-	0.5	1.2	1.5
TOP-220HBM	30.0	-	0.4	1.2	1.2	36.0	-	0.3	0.9	1.2

Above data was taken by the oil:ISO-VG 46 at 40 Celsius

2MY-2HWM

本公司坐落在中国经济特区、全国性经济中心城市和国际化城市--深圳，本公司有着十几年丰富的经验，一直本着兢兢业业的态度做事，诚诚恳恳的态度做人的经营理念，在质量上严格把控，在服务上热情耐心，广交各方好友，欢迎您随时联系我们或来实地查看！！
我们公司原厂直销，货期短，无中间环节,价格更有优势，品质更有保证！！

感谢您关注我们的产品，如以下图片和型号不符请联系我们咨询，谢谢！
