日本SHIMPO新宝减速机VRL-120B-8-K5-38KA35
ABLE reducers VRL series
Handling company: NIDEC DRIVE TECHNOLOGY CORPORATION
Reducer lineup with excellent cost performance and the smallest class models in the industry.
ABLE reducers meet various customer's requests.
Features:
compact, silent, high-precision, high rigidity, high torque, mountable on any motors all over the world, no grease leakage, maintenance-free
Product data
Basic information
Size 050C、070C、090C、120C、155C、205C、235C Reduction ratio 3 ～ 100 Backlash Backlash 5 arc-minutes (Size 050 2 stage reducer only has a backlash of 7 arcminutes) Nominal output torque ＊1 6 ～ 1500Nm Maximum output torque ＊2 12 ～ 2300Nm Emergency stop torque ＊3 30 ～ 5000Nm Nominal input speed ＊4 1000 ~ 4000rpm Maximum input speed ＊5 2000 ~ 8000rpm Allowable radial load ＊6 240 ～ 15000N Allowable axial load ＊7 270 ～ 14000N Maximum radial load ＊8 710 ~ 15000N Maximum axial load ＊9 640 ~ 14000N Weight ＊10 0.7 ～ 57kg ＊1 With nominal input speed, service life is 20,000 hours. ＊2 The maximum torque when starting and stopping. ＊3 The maximum torque allowed under a stress situation. Permitted 1,000 times during service life. ＊4 The maximum average input speed ＊5 The maximum momentary input speed. ＊6 With this load and nominal input speed, service life will be 20,000 hours. (Applied to the output shaft center, at axial load 0) ＊7 With this load and nominal input speed, service life will be 20,000 hours. (Applied to the output side bearing, at radial load 0) ＊8 The maximum radial load the reducer can accept. ＊9 The maximum axial load the reducer can accept. ＊10 The weight may vary slightly model to model.
