日本山田YAMADA雅玛达隔膜泵NDP-25BST
发布时间：2024-07-31
日本山田YAMADA雅玛达隔膜泵NDP-25BST
Yamada® NDP-25BST series Air Powered Double Diaphragm (AODD) pumps provide a maximum flow rate of 49 gallons per minute. Pumps are available in aluminum, stainless steel (316), cast iron, polypropylene, and Kynar construction, with a wide variety of diaphragm materials.
| Inlet (in) | 1 |
| Outlet (in) | 1 |
| Max Flow (gpm) | 46.2 |
| Max Temp | 212 |
| Max Solid (in) | 3/16 |
| Valve Type (in) | 3/8 |
| Air Motor Material | Aluminum |
| Body Material | Stainless Steel |
| Elastomer Material | PTFE |
| Documentation | |
| Performance Curve | ndp-25T_perf-curve_lrg.jpg |
| BOM | NDP-25BST_Bill_of_Material.pdf |
| CAD Drawings (PDF) | PUMP_NDP-25_CAD_SS.pdf |
| CAD Drawings (DWG) | PUMP_NDP-25_CAD_SS.dwg |
