Compact size, high power (0.7W-26W).
Variety of line ups (224 mode in all).
For variety of gear heads (32 Dia-80 Sq and others).
Features:
Long-life: Intermittent operation over 1 million cycles with optimized brush design.
Continuous operating life of 1000 hours.
High output: High heat dissipation and heat resistance achieves higher output.
High strength: High radial load capacity due to robust construction, large diameter output shaft and ball bearings.
Low noise and increased insulation due to new
more
Unit of Measure
Product Type | DC Motor with Gearbox 6DG |
Series | DME33 |
Model Code | BB |
Frame Size | 61 x 49.5 mm2.402 x 1.949 in |
Diameter | 1.26 in32 mm |
Gear Ratio | 250 |
Rated Output | 3.0 W |
Rated Voltage | 24 V |
Current Rating | 220 mA0.22 A |
Rated Speed | 16 r/min |
Rated Torque | 138.87 oz·in0.98 N·m |
Note | 6DG gearbox are available with either 4.5 mm diameter mounting holes or M4 x 6 mm tapped holes.
|
