日本麦格特MIGHTY联轴器MJC-19-5x8-TB
发布时间：2024-07-02
日本麦格特MIGHTY联轴器MJC-19-5x8-TB
Flexible Shaft Coupling (MJC-19-5X8)
Oldham, Clamping, MJC Series
Part Number: MJC-19-5X8
•Application : Encoder, Servo Motor, Standard, Stepping Motor
•Body Material : Aluminum Alloy
•Allowable Misalignment : Angular, Eccentricity
•Feature : High Accuracy, High Durability, No Backlash, Vibration Insulation
For complete product overview and details on Oldham Coupling, MJC Series see the sections below:
Configured Specifications
Download| Type | Oldham | Allowable Misalignment | Angular Misalignment / Eccentricity |
|---|---|---|---|
| Application | Standard / Servo Motor / Stepping Motor / Encoder | Allowable Torque Range(N⋅m) | 1.01 to 3.00 |
| For Shaft Size D1(mm) | 5 | For Shaft Size D2(mm) | 8 |
| Outer Diameter A(Ø) | 19.1 | Overall Length W(mm) | 22 |
| Features | High accuracy / High durability / Backlash 0 / Vibration Absorption | Body Material | [Aluminum] Aluminum Alloy |
| Allowable Torque(N⋅m) | 1.7 | Allowable Angular Misalignment(deg) | 1 |
