KURODA黑田精工气动元件电磁阀

Technical Specifications

• Wiring:Without connector and lead wire (Side outlet)-NPN Type

• Valve Configuration Type:Single solenoid (High speed response type)

• Mounting Option:In-line

• Options:Vacuum/Positive pressure

• Function:4/2 Single

• For Fluid Type:Air

• Maximum Operating Temperature:40 to 50 °C

• Maximum Flow Rate:80 to 120 L/min

• Configuration:N/A

• Minimum Operating Temperature:-18 to 0 °C

• Mounting Type:Free

• Actuation Type:Pneumatic

• Maximum Operating Pressure:7 to 10 bar

• Function:2 Position 4-Way

• Body Material:Synthetic Resin

• Seal Material:Nitrile (NBR)

• Media:Non-lubricated air

• Port Size:M3

• Flow Rate:0.05 Cv

• Operating Temperature:-5 to 50 °C

• Pressure Rating:-100kPa to 0.8MPa

• Response Time:ON/OFF 3/1.5 ms

• Override Functionality:Non-lock type push button

• Mounting Position:Free

• Vibration Resistance:150/30 m/sec2

• Weight:26.3 g

• Input Voltage:24 VDC

• Power Consumption:4 W

• Insulation:JIS grade B

• Valve Option:Direct Acting Pneumatic Valve

Item Information

VA01_23&24 series are ideal for quick pick and place, small size cylinder high speed operation, clean air blow and clean media switching applications for microelectronics, life science and etc. applications.

–Vacuum and positive pressure are available in one valve. (VA01_24).
-Exceedingly long life based on reliable double poppets structure (500 million cycles: VA01_24).
-Ultra quick response time/ stable operation (3ms: VA01HPSC24). Balanced poppets and direct solenoid mechanism make it available for quick and stable response time.
-Low power consumption (1W: VA01_23). -Compact (10mm width), light weight and large flow (0.05Cv).
-Extremely low particle generation (oil-free). Double poppets structure, which has no friction parts without lubricating oil, realizes the extremely clean air blow. Furthermore, the direct operated solenoid has no valve breathing and pilot air exhaust, and the valve does not pollute outside environment.
-One coil latch solenoid, which holds the air switching position by permanent magnet, is ideal for keeping vacuum position in case of power cut.
